CX206Y-48GT-M-H, 48x 1G RJ45, 6x 25G SFP28, PoE+ Switch

SKU:

48xPoE+ & 8xPoE++(@740W/1440W) | Marvell AlleyCat5X | SONiC OS

  • 48-Port Gigabit Ethernet Layer 3 Switch with 25G uplinks.
  • Rich Layer 2/3 with VXLAN & MC-LAG support.
  • Enterprise SONiC Distribution preload.
  • Optional both PoE+ (802.3at) and PoE++ (802.3bt) ports.
  • Optional PoE power budget: 740W or 1440W.
Request Discount

Asteraix 48-port ethernet switch CX206Y-48GT has 48x 1G RJ45 ports and 6x 25G SFP28/10G SFP+ ports, offering a total switching capacity of 210Gbps. This L3 ethernet switch is well-suited for enterprise layer 3 distribution and access networks. - 48x 1GbE ports and 6x 25GbE ports uplinks

  • Easy switch management with Asteria campus controller
  • Quick and easy setup
  • Advanced L2/L3 network features (4K VLANs, MC-LAG, storm control, IPv4/v6 Dual Stack, BFD, etc.)
  • Fan design (airflow front to rear, 2+1 hot-pluggable)
  • Power Support Unit design (1+1 hot-pluggable)
  • Limited 2-year warranty
  • Enterprise SONiC OS is supported
Data Plane Ports (25G)6x25GbE QSFP28, downgradable to 6x 10GbE
Data Plane Ports (1G)48x1Gb/100M/10MBase-T copper
PoE Ports (Optional)1GBase-T 48-port PoE+(30Watt), 1~8 port PoE++ (60Watt), total 740W/1440Watt budget
PoE StandardIEEE 802.3af/at/bt
Switch ASICMarvell AlleyCat5X
Switching Capacity210Gbps
Forwarding Rate510Mpps
Packet Buffer3MB
Management Ports1xUSB2.0, 1xConsole RJ45, 1xMGMT RJ45
Control CPUMulti-core ARM64
Control Plane Memory4GB DDR4/32GB eMMC
Nexthop8K
Mac Addr. Entries32K
IPv4 Prefix Routes32K
IPv6 Prefix Routes16K
Power Module1+1 Hot- pluggable
FAN Modules2+1 Hot-pluggable
Max Power Consumption126Watt(131Watt w/o PoE)
Input Range100- 240V AC / 36-72V DC (w/o PoE)
Rack Space1RU
AirflowFront to Rear
Dimension (HxWxD)44x440x290mm
Weight8.3KG(9.3KG)
Op.Temperature0 - 45℃ (32 to 113°F)
Op. Humidity5% - 90% (non-condensing)
