CX204Y-48GT-M-S, 48x 1G RJ45, 4x 25G SFP28, PoE+ Switch

SKU:

48xPoE+ & 8xPoE++(@740W) | Right to Left Airflow | Marvell AlleyCat5X

  • 48-Port Gigabit Ethernet Layer 3 Switch with 25G uplinks.
  • Rich Layer 2/3 with VXLAN & MC-LAG support.
  • Enterprise SONiC Distribution preload.
  • Optional both PoE+ (802.3at) and PoE++ (802.3bt) ports.
  • Optional PoE power budget: 740W.
Request Discount

Asteraix Enterprise 48-port switch CX204Y-48GT has 48x 1G RJ45 ports and 4x 25G SFP28/10G SFP+ ports, offering a total switching capacity of 210 Gbps. It supports a maximum of 48-port 30W PoE+ (802.3at), of which 8 ports can be configured as 60W PoE++ (802.3bt). This 48-port PoE+ switch is well-suited for enterprise layer 3 distribution and access networks. - 48x 1GbE ports and 4x 25GbE ports uplinks

  • Easy switch management with Asteria campus controller
  • Quick and easy setup
  • Advanced L2/L3 network features (4K VLANs, MC-LAG, storm control, IPv4/v6 Dual Stack, BFD, etc.)
  • Fan design (airflow right to left, 3 built-in)
  • Power Support Unit design (1 built-in)
  • Limited 2-year warranty
  • Enterprise SONiC OS is supported
Data Plane Ports (25G)4x25GbE QSFP28, downgradable to 4x 10GbE
Data Plane Ports (1G)48x1Gb/100M/10MBase-T copper
PoE Ports1GBase-T 1~8 PoE++ (60Watt), total 740Watt budget
PoE StandardIEEE 802.3af/at/bt
Switch ASICMarvell AlleyCat5X
Switching Capacity210Gbps
Forwarding Rate510Mpps
Packet Buffer3MB
Management Ports1xUSB2.0, 1xConsole RJ45, 1xMGMT RJ45
Control CPUMulti-core ARM64
Control Plane Memory4GB DDR4/32GB eMMC
Nexthop8K
Mac Addr. Entries32K
IPv4 Prefix Routes32K
IPv6 Prefix Routes16K
Power Module1 Built-in
FAN Modules3 Built-in
Max Power Consumption72Watt(74Watt w/o PoE)
Input Range100- 240V AC
Rack Space1RU
AirflowRight to Left
Dimension (HxWxD)44x440x290mm
Weight3.8KG(4.5KG)
Op.Temperature0 - 45℃ (32 to 113°F)
Op. Humidity5% - 90% (non-condensing)
