CX204Y-24GT-M-S, 24x 1G RJ45, 4x 25G SFP28, Layer 3 Access Switch

SKU:

24x PoE+ & 8x PoE++(@370W/740W) | Right to Left Airflow | Marvell AlleyCat5X

  • 24-Port Gigabit Ethernet Layer 3 Switch with 25G uplinks.
  • Support MLAG, VXLAN, QoS, BFD, IPSG, IPv6, etc.
  • Enterprise SONiC Distribution preload.
  • Optional both PoE+ (802.3at) and PoE++ (802.3bt) ports.
  • Optional PoE power budget: 370W or 740W.
Request Discount

Asteraix's Campus 24 port PoE+ ethernet switch CX204Y-24GT has 24x 1G RJ45 ports and 4x 25G/10G SFP28 ports, offering a total switching capacity of 180Gbps. It supports a maximum of 24 ports 30W PoE+ (802.3at), of which 8 ports can be configured as 60W PoE++ (802.3bt) for IP surveillance systems, Wi-Fi access points, or other standards-compliant PoE and PoE+ end network devices. This access switch is ideal for enterprise layer 3 distribution and access networks. - 24x 1GbE ports and 4x 25GbE ports uplinks

  • Easy switch management with Asteria campus controller
  • Quick and easy setup
  • Advanced L2/L3 network features (4K VLANs, MC-LAG, storm control, IPv4/v6 Dual Stack, BFD, etc.)
  • Fan design (airflow right to left, 2 built-in)
  • Power Support Unit design (1 built-in)
  • Limited 2-year warranty
  • Enterprise SONiC OS is supported
Data Plane Ports (25G)4x25GbE QSFP28, downgradable to4x 10GbE
Data Plane Ports (1G)24x1Gb/100M/10MBase-T copper
PoE Ports (Optional)1GBase-T 24-port PoE+(30Watt), 1~8 port PoE++ (60Watt), total 370W/740Watt budget
PoE StandardIEEE 802.3af/at/bt
Switch ASICMarvell AlleyCat5X
Switching Capacity180Gbps
Forwarding Rate510Mpps
Packet Buffer3MB
Management Ports1xUSB3.0, 1xConsole RJ45, 1xMGMT RJ45
Control CPUMulti-core ARM64
Control Plane Memory4GB DDR4/32GB eMMC
Nexthop8K
Mac Addr. Entries32K
IPv4 Prefix Routes32K
IPv6 Prefix Routes16K
Power Module1 Built-in
FAN Modules3 Built-in
Max Power Consumption63Watt(66Watt w/o PoE)
Input Range100- 240V AC / 36-72V DC (w/o PoE)
Rack Space1RU
AirflowRight to Left
Dimension (HxWxD)44x440x290mm
Weight3.6KG(4.3KG)
Op.Temperature0 - 45℃ (32 to 113°F)
Op. Humidity5% - 90% (non-condensing)
