100G QSFP28 ER4 LAN WDM 40km Duplex LC

SKU:

< 5.5 W | EML | 40km | SMF

  • 100G data rate via 4 × LAN-WDM lanes (~27.95 Gb/s each)
  • Extended reach up to 40 km over single-mode fiber (1310 nm)
  • Duplex LC interface for SMF connection
  • Hot-pluggable QSFP28 form factor
  • Low power consumption (< 5.5 W)
  • Real-time monitoring with DDM/DOM support
  • Built-in TX and RX clock/data recovery (CDR)
  • Fully compliant with QSFP28 MSA, IEEE 802.3ba 100GBASE-ER4, and OTU4/ITU-T G.959.1 standards
  • Operating temperature range: 0 – 70 °C (case), storage: –20 – 85 °C
Request Discount

The 100GBASE ER4 standards are met by the 100G QSFP28 ER4 transceiver module. The maximum reach distance with single-mode fiber is 40 km. Real-time digital diagnostic monitoring of many transceiver and optical link parameters is supported by the 100G ER4 transceiver. Four channels of 25Gb/s electrical data are converted into four channels of LAN-WDM optical signals by this transceiver, which then multiplexes them into a single 100Gb/s optical stream for transmission. It skillfully de-multiplexes a 100Gb/s optical input back into four separate LAN-WDM optical signal channels on the receiving end. The 100GbE IEEE 802.3ba 100GBASE-ER4 and ITU-T G.959.1 OTU4 (4L1-9C1F) specifications are met by this optical module.

Form FactorQSFP28
ConnectorDuplex LC
MediaSMF
Max. Cable Distance40km
Data Rate111.8Gbps(4x27.95Gbps)
Wavelengths Range1310nm LWDM4
Transmitter TypeEML
Receiver TypePIN
Extinction Ratio>8dB
Supply Voltage3.3V
Op. Temperature0 to 70°C (32 to 158°F)
Humidity(non-condensing)5-85%
St. Temperature-20 to 85°C (-4 to 185°F)
Electrical InterfaceHot-pluggable
DDM/DOMSupported
Protocols100G Ethernet Compliant
