100G QSFP28 DR1 1310nm 500m Duplex LC Single Lambda

SKU:

< 4 W | EML | 500m | SMF

  • 100 G data rate via 4×25.781 Gb/s CAUI-4 (PAM4) lanes
  • Up to 500 m reach over single-mode fiber (1310 nm)
  • Duplex LC connector for SMF interface
  • Hot-pluggable QSFP28 form factor
  • Low power consumption (< 4 W)
  • Real-time monitoring with DDM/DOM support
  • Compliant with QSFP28 MSA and IEEE 802.3cu (100GBASE-DR1) standards
  • Operating temperature range: 0–70 °C
Request Discount

With KP-FEC, the 100GBASE-DR1 QSFP28 transceiver module can communicate up to 500m in G.652 SMF. The transceiver 100Gbase DR1 is compatible with IEEE 802.3cu 100GBASE-DR1 and also the QSFP28 Multi-Source Agreement (MSA). Signal processing is enhanced thanks to the digital 100G signal processing (DSP) that can handle data rates aggregating to 106.25 Gb/s. Its power consumption of only 4 watts and commercial temperature range from 0 to 70 degrees Celsius help to improve its energy efficiency. For reliable operation with a range of up to 500m, the optical module comes with a VCSEL with four channels of 1310 nm array and a PIN detector. It also comes with routers or switches, a 4:1 breakout with 400GBASE-DR4, and reliable connectivity within the center of data. Because it conforms to RoHS and RoHS, it's an environmentally friendly option for modern networking settings.

Form FactorQSFP28
ConnectorDuplex LC
MediaSMF
Max. Cable Distance500m
Data Rate100Gbps
Wavelengths Range1310nm
Transmitter TypeEML
Receiver TypePIN
TX Power-2.9~4dBm
RX Power-5.9~4dBm
Extinction Ratio>3.5dB
Supply Voltage3.3V
Op. Temperature0 to 70°C (32 to 158°F)
DSPTx and Rx
DDM/DOMSupported
Inbuilt FECYes
Electrical InterfaceHot-pluggable
ProtocolsIEEE 802.3cu, QSFP28 MSA
